10.2 inch TFT LCD CLAA102NDA1 CW for Industrial HMI

The CPT CLAA102NDA1 CW is a 10.2-inch a-Si TFT-LCD LCM designed for industrial OEM and embedded display applications. Its WSVGA 1024 × 600 resolution, 600 brightness, 1000:1 typical contrast ratio, WLED backlight, and single-channel LVDS interface support compact, visually clear HMI and information-display solutions across a wide operating temperature range.

Features

• 10.2-inch a-Si TFT-LCD LCM with a 1024 (RGB) × 600 WSVGA resolution
• Transmissive, normally white TN display mode
• Brightness of 600 with a typical contrast ratio of 1000:1
• Typical response time of 25 ms (Tr + Td) and 60 Hz refresh rate
• Viewing angle of 70/70/55/65 degrees (typical, CR ≥ 10)
• 16.7M color depth using 6-bit + Hi-FRC, with 262K-color 6-bit support
• 97% sRGB coverage based on CIE 1931 and a specified color temperature of 6914K
• Single-channel LVDS interface supporting 6-bit and 8-bit configurations
• WLED backlight with a typical lifetime of 70K hours
• Wide operating temperature range of -30 to 85 °C and storage temperature range of -40 to 90 °C
• Typical operating voltage of 11.6 V and typical power consumption of 4.18 W
• Outline dimensions of 236 × 148 mm with a 222.72 × 130.5 mm active area
• Pixel pitch of 0.0725 × 0.2175 mm
• Listed weight of 1

Applications

• Industrial human-machine interface (HMI) systems
• Factory automation and process-monitoring displays
• Test, measurement, and diagnostic equipment
• Machine-control and equipment-status panels
• Embedded information and operator terminals
• OEM display systems requiring LVDS integration

What display configuration does the CPT CLAA102NDA1 CW provide?

It is a 10.2-inch a-Si TFT-LCD LCM with a 1024 (RGB) × 600 WSVGA resolution. The panel uses a transmissive, normally white TN display mode.

What are the brightness and contrast characteristics?

The specified brightness is 600, with a typical transmissive contrast ratio of 1000:1. The backlight uses WLED technology with a typical lifetime of 70K hours.

Which display interface is supported?

The CLAA102NDA1 CW supports a single-channel LVDS interface with 6-bit and 8-bit configurations.

What operating and storage temperature ranges are specified?

The operating temperature range is -30 to 85 °C, while the storage temperature range is -40 to 90 °C.

What are the panel dimensions and viewing area?

The outline dimensions are 236 × 148 mm, and the active area measures 222.72 × 130.5 mm. The listed weight is 1.

What are the electrical specifications?

The typical operating voltage is 11.6 V, and the typical power consumption is 4.18 W. The panel refresh rate is 60 Hz.

What viewing angle and response time are specified?

The typical viewing angle is 70/70/55/65 degrees at CR ≥ 10, and the typical response time is 25 ms for Tr + Td.

What color capabilities are available?

The panel supports 262K colors at 6-bit and 16.7M colors at 6-bit + Hi-FRC. It provides 97% sRGB coverage based on CIE 1931, with a specified color temperature of 6914K.
