10.4 inch TFT LCD Module for Industrial HMI - G104VN01 V111

The AUO G104VN01 V111 is a 10.4-inch a-Si TFT-LCD LCM engineered for industrial display integration. It delivers a 640 × 480 VGA resolution, 450 brightness rating, 700:1 typical contrast ratio, and a 60Hz refresh rate. The transmissive, normally white TN panel supports operating temperatures from -30°C to 85°C and uses a single-channel LVDS interface with 6/8-bit color support.

Features

• 10.4-inch a-Si TFT-LCD LCM with a normally white, transmissive TN display mode
• 640 RGB × 480 VGA resolution with 76 PPI pixel density
• Brightness rating of 450 and typical contrast ratio of 700:1
• Typical response time of 20/10ms for rise and fall transitions
• Typical viewing angles of 80/80/60/80 degrees at CR ≥ 10
• Wide operating and storage temperature range from -30°C to 85°C
• Single-channel LVDS interface with 6/8-bit color support
• 60Hz refresh rate with 65% sRGB coverage based on CIE 1931
• Color temperature of 6638K
• Active display area of 211.2 × 158.4mm
• Outline dimension of 8.5 ± 0.5mm
• Pixel pitch of 0.110 × 0.330mm
• Typical power consumption of 5.2W
• Minimum backlight lifetime of 50,000 hours

Applications

• Industrial human-machine interfaces and operator panels
• Factory automation and process-monitoring systems
• Test, measurement, and diagnostic equipment
• Industrial inspection and data-acquisition terminals
• Compact embedded information displays

What display configuration does the AUO G104VN01 V111 provide?

The G104VN01 V111 is a 10.4-inch a-Si TFT-LCD LCM with a normally white, transmissive TN mode. It provides a 640 × 480 VGA resolution at 76 PPI and operates at a 60Hz refresh rate.

What are the brightness and contrast specifications?

The panel has a brightness rating of 450 and a typical transmissive contrast ratio of 700:1. Its typical response time is 20/10ms for rise and fall transitions.

Which interface and color depth does the module support?

The display uses a single-channel LVDS interface with 6/8-bit color support. Its specified sRGB coverage is 65% based on CIE 1931, with a color temperature of 6638K.

What environmental conditions are supported?

Both the operating and storage temperature ranges are specified from -30°C to 85°C, making the module suitable for industrial environments with broad temperature requirements.

What are the module dimensions and active viewing area?

The active area measures 211.2 × 158.4mm, and the specified outline dimension is 8.5 ± 0.5mm. The listed module weight is 1.

What are the electrical and backlife specifications?

The specified voltage is 25.5V typical and 29.2V maximum. Typical power consumption is 5.2W, and the minimum backlight lifetime is 50,000 hours.
