COM50H5N17ULC Ortustech 5 inch 720(RGB)×1280 lcd display screens

Ortustech COM50H5N17ULC - 5.0 inch HD Blanview TFT-LCD Module

The Ortustech COM50H5N17ULC is a 5.0-inch HD (720x1280) Blanview TFT-LCD module manufactured by TOPPAN INC. under the Ortustech brand. Ortustech, a division of Toppan Printing Co. Ltd., is a world-renowned specialist in small-to-medium-sized TFT LCD modules for industrial, medical, and specialty applications.

Featuring proprietary Blanview TFT-LCD technology, this display delivers transflective performance — combining a transmissive backlit mode for indoor use with a reflective mode for sunlight readability. This makes the COM50H5N17ULC exceptionally suited for outdoor and high-ambient-light environments where conventional transmissive LCDs struggle.

Why Choose Ortustech COM50H5N17ULC?

• Blanview Technology: Proprietary Toppan Blanview TFT provides best-in-class sunlight readability via transflective design - simultaneously transmissive (backlit) and reflective (ambient light).

• HD Portrait Resolution: 720x1280 pixels (296 PPI) in 5.0-inch diagonal provides sharp, high-contrast imagery ideal for portable and handheld industrial devices.

• MIPI DSI Interface: High-speed MIPI Display Serial Interface (4 data lanes) suitable for modern embedded processors and SoCs. Built-in timing generator and power supply circuitry.

• Wide Viewing Angles: 80/80/80/80deg viewing angles ensure consistent image quality from all directions - critical for group viewing and portable device positioning.

• Ultra-Slim Profile: Only 2.4mm module depth with 67.84mm x 120.22mm outline - ideal for space-constrained portable and wearable designs.

• No Touch Panel: Clean display without integrated touch - compatible with external capacitive or resistive touch overlays for design flexibility.

Technical Specifications

Typical Applications

• Industrial Handheld Devices: Portable industrial terminals, barcode scanners, and field instruments requiring sunlight-readable displays with wide temperature range.

• Outdoor Meters and Gauges: Utility meters, environmental monitoring equipment, and agricultural instruments operating in direct sunlight.

• Medical Devices: Portable diagnostic equipment, patient monitoring devices, and handheld medical instruments requiring reliable, high-contrast displays.

• Portable Instrumentation: Oscilloscopes, signal analyzers, and test equipment with high pixel density in a compact form factor.

• Wearable Industrial Displays: Augmented reality headsets, head-mounted displays, and wearable computing devices.

Quality Assurance and Warranty

• Pre-Shipment Testing: Each panel is individually tested for pixel integrity, brightness uniformity, and electrical functionality prior to shipping.

• 1-Year Warranty: Coverage against defects in materials and workmanship under normal use.

• Authentic Ortustech/TOPPAN Product: Guaranteed genuine TOPPAN INC. manufactured panel under the Ortustech brand - not a compatible substitute or clone.

• Technical Support: Available for product selection assistance and basic application guidance.

Packing and Shipping

• Packaging: Anti-static protective film + foam cushioning + double-wall carton box.

• Shipping: DHL, FedEx, UPS, TNT - worldwide delivery within 3-6 working days.

• MOQ: 1 piece.
