LCD Display for TK6100iV5WV HMI

Weinview TK6100IV5WV 10.1-Inch Industrial TFT-LCD Panel

The TK6100IV5WV is a 10.1-inch industrial-grade TFT-LCD display panel — this listing most likely represents the LCD module sourced from the Weinview TK6100IV5WV HMI (Human Machine Interface) terminal. Weinview  is a well-known manufacturer of industrial HMI touch-screen terminals used in factory automation, building management, and process control applications globally.

Important Classification Note: The TK6100IV5WV is primarily known as a complete HMI operator interface terminal (with integrated touchscreen and controller). This listing represents the LCD display module only — not the complete HMI unit with touch glass and housing. The LCD panel inside the TK6100IV5WV HMI has the specifications listed below. Buyers seeking the complete HMI terminal (with touch screen, case, and controller) should confirm with InvShop whether this listing is for the panel only or the complete unit.

Technical Specifications

About Weinview and the TK Series

Weinview  is a professional manufacturer of industrial Human Machine Interface (HMI) terminals and touch-screen operators panels. The TK series represents Weinview's value-line compact HMI terminals featuring integrated touch screens, PLC communication ports (RS-232, RS-485, Ethernet), and easy-to-use configuration software (EasyBuilder).

The TK6100IV5WV is a 10.1-inch model in Weinview's TK-i series — the "i" designation indicates an integrated design with the display, touch screen, and control electronics in a single compact unit. The HMI terminal specifications typically include:

• 400 MHz ARM processor for smooth screen updates

• 24V DC supply (standard industrial power)

• NEMA4/IP65 front panel sealing for industrial wash-down environments

• Multiple PLC communication drivers (Mitsubishi, Siemens, Omron, Delta, and 200+ other brands)

• USB and RS-232/RS-485 ports for connectivity

This invshop listing for the TK6100IV5WV LCD panel likely represents the display module recovered from or sourced as spare parts for these HMI units.

Applications

• HMI Display Replacement: Spare or replacement LCD panel for Weinview TK6100IV5WV HMI terminals in factory automation and process control systems

• Industrial Embedded Displays: Standalone display module for custom industrial embedded systems, test equipment, and instrumentation

• Point-of-Sale (POS) Terminals: Commercial display for retail POS systems, self-service kiosks, and ordering terminals

• Medical Device Displays: Industrial-grade LCD for medical monitoring and diagnostic equipment requiring reliable long-term display

• Automotive and Transportation: In-vehicle displays, fleet management terminals, and transportation ticketing systems

Quality and Testing

All TK6100IV5WV LCD panels are individually tested and verified "Test OK before shipping" before listing. Testing includes visual inspection for dead pixels, uniform backlight illumination, and correct LVDS signal display. Panels are shipped in anti-static packaging with adequate cushioning to prevent mechanical damage during transit.

Frequently Asked Questions
