Powertip PG12864K LCD Display Module Overview

The Powertip PG12864K is a 3.0-inch STN graphic LCD display module with 128×64 pixel resolution, featuring the industry-standard ST7920 LCD controller with a built-in 8,192 Chinese character glyph library (CGROM). Manufactured by Powertip Technology Corporation, a leading Taiwanese LCD module specialist established in 1991, the PG12864K is designed for embedded applications in industrial controls, instrumentation, POS systems, and consumer electronics requiring reliable alphanumeric and graphic display capabilities.

About Powertip Technology Corporation

Powertip Technology Corporation is headquartered in Taichung, Taiwan, with production facilities in both Taiwan and Nanjing, China. Founded in 1991, Powertip specializes in the research, development, and manufacturing of LCD display modules serving major industries including medical devices, industrial control, automotive, home appliances, communications, meters, and POS applications. The company offers a comprehensive product range spanning from COG and SMT LCD modules to 1.44" to 23" TFT displays with projected capacitive touch panels. Powertip's embedded display solutions include proprietary MCU/MPU control boards and SoM module families, enabling customers to accelerate time-to-market with complete display optical performance design, mechanical development, BSP, and workflow UI support.

Technical Specifications

ST7920 Controller Features

• Built-in Chinese Character CGROM: 8,192 fully documented Chinese character glyphs for simplified Chinese interface design

• Dual Interface Support: 8-bit parallel 6800 interface and 3-wire SPI serial interface for flexible MCU connectivity

• Graphic Display Capability: 64×32-bit GDRAM (Graphic Display RAM) for custom bitmap patterns

• Internal Reset Circuit: Reduces external reset circuitry requirements

• Low Power Consumption: CMOS technology for battery-powered portable applications

• Wide Application Compatibility: Widely supported by Arduino libraries, STM32, PIC, and AVR microcontroller platforms

Typical Applications

• Industrial Control Panels: HMI displays for PLC systems, temperature controllers, and process automation equipment

• POS Terminals: Point-of-sale receipt printers, cash registers, and barcode scanner displays

• Laboratory Instruments: Digital multimeters, oscilloscopes, and measurement equipment interfaces

• Home Appliances: Microwave ovens, washing machines, and air conditioner control panels with Chinese character support

• Communications Equipment: Telephone systems, intercom panels, and access control displays

• Consumer Electronics: Audio equipment, gaming devices, and handheld instrumentation

• Automotive Aftermarket: GPS navigators, car reversing systems, and dashboard displays

Quality Assurance and Support

• ✓ 100% Genuine Powertip Product: Authentic Powertip Technology Corporation LCD module from authorized supply chain

• ✓ Pre-Shipment Testing: Every module electrically tested for display function, controller operation, and pixel integrity before shipping

• ✓ Datasheet Available: Full technical specification (PG12864K datasheet) downloadable

• ✓ Arduino & MCU Library Support: Widely supported by open-source libraries (u8g2, LiquidCrystal) for rapid prototyping

• ✓ Fast Shipping: Ships within 1-3 business days from China warehouse (820 units in stock)

• ✓ Anti-Static Packaging: Each module packaged in anti-static bag with bubble wrap and carton box protection

• ✓ 90-Day Warranty: Coverage for manufacturing defects and functional failures

Interface Connection Reference

The ST7920 controller typically uses a 20-pin interface header. Key signals include: DB0-DB7 (8-bit parallel data bus), RS (Register Select), R/W (Read/Write), E (Enable), PSB (Parallel/Serial select), and reset. For serial mode, only 3 wires (CS, SID, SCLK) are required for SPI communication.
